DDS-84ABC Signal Light Battery
Ship signal light battery pack parameters:
Combination: 5/3C18650-7S3P
Model specification: 24V/7000mAh
Discharge cut-off voltage: 19V
Nominal lithium battery voltage: 24V
Charging voltage: 29.4V
Operating Temperature: -10~60°C
The following are adjustable parameters:
Product size: according to customer requirements
Finished product internal resistance: ≤180mΩ
Protection board: Seiko configuration
Protection parameters: overcharge protection voltage/per string 4.25±0.05V
Over-discharge protection voltage 2.7±0.05V
Overcurrent value 8-12A
Size: 127*56*72mm (adjustable)
